What is the difference between LoRa and LoRaWAN?

LoRa is the radio technology (like WiFi radio). LoRaWAN is the network protocol that manages thousands of devices. Link485 Zero uses point-to-point LoRa (simple, no infrastructure needed). Link485 LoRaWAN connects to LoRaWAN networks for large-scale deployments with centralized management.

Do I need my own LoRaWAN gateway?

Yes, Link485 LoRaWAN is an end device that connects TO a LoRaWAN gateway (not a gateway itself). You'll need LoRaWAN gateway infrastructure or use public networks like The Things Network. One LoRaWAN gateway can serve 1000+ Link485 LoRaWAN devices.

Is it compatible with The Things Network (TTN)?

Yes! Link485 LoRaWAN is fully compatible with The Things Network (TTN). It supports both TTN v2 and v3. You can use free public TTN coverage or deploy private TTN gateways. Device profile and payload decoders provided for easy integration.

Does it work with ChirpStack?

Yes! Link485 LoRaWAN works perfectly with ChirpStack v3 and v4. It supports OTAA and ABP activation. Device templates and codec functions are provided. Many customers use ChirpStack for private LoRaWAN networks with full control.

What is OTAA and ABP activation?

OTAA (Over-The-Air Activation) is the secure method where device negotiates keys with network - recommended for production. ABP (Activation By Personalization) uses pre-configured keys - useful for testing or fixed installations. Link485 LoRaWAN supports both.

What is Class A and Class C operation?

Class A: Device wakes up to send data, then listens briefly for downlinks - ultra-low power (3-10 year battery life). Class C: Device listens continuously for downlinks - allows instant configuration changes but uses more power (mains powered). Link485 LoRaWAN supports both.

How many devices can one LoRaWAN gateway serve?

A single LoRaWAN gateway can handle 1000-10000+ end devices depending on message frequency. For example, with 1000 devices sending every 5 minutes, a gateway operates at only 10% capacity. Link485 LoRaWAN uses adaptive data rate (ADR) for optimal network efficiency.

Can I use it for battery-powered sensors?

Yes! Link485 LoRaWAN is optimized for ultra-low power. With 3xAA batteries and 15-minute reporting interval, expect 3-5 years of operation. Configurable sleep modes, adaptive data rate, and efficient Modbus polling maximize battery life.

Does it support AWS IoT Core for LoRaWAN?

Yes! Link485 LoRaWAN is compatible with AWS IoT Core for LoRaWAN. Device profiles and service profiles are provided. You can integrate with AWS Lambda, DynamoDB, and other AWS services for scalable IoT applications.

When will new stock be available?

New stock is expected to arrive within 2-3 weeks. Contact us to get notified when units become available or to place a pre-order. Current lead time for custom orders is 4-6 weeks.

Link485 LoRaWAN

Name: Link485 LoRaWAN - LoRaWAN Network Modbus Bridge
Brand: LINK485
SKU: L485-LW-NA-IN
Price: 42000 INR
Availability: OutOfStock
Rating: 4.7 (12 reviews)

LoRaWAN Network Modbus Bridge

★★★★☆ (4.7/5 from 12 reviews)

Link485 LoRaWAN integrates your Modbus devices with LoRaWAN networks, enabling long-range sensor deployments with centralized network management. Compatible with ChirpStack, The Things Network (TTN), and enterprise LoRaWAN Network Servers.

🌐

Network Ready ChirpStack, TTN compatible

📡

10+ km Range Long-range sensor networks

🔋

Low Power Class A & C operation

Pre-Order Inquiry Download Datasheet

Planned Features

LoRaWAN 1.0.3

Full LoRaWAN 1.0.3 specification compliance with OTAA and ABP activation modes.

Class A & C

Support for both Class A (battery-powered) and Class C (low-latency) operation modes.

Multi-Region

Support for IN865, EU868, US915, AU915, AS923 frequency plans with regional variants.

Network Server Integration

Pre-configured integration with ChirpStack, TTN, AWS IoT Core for LoRaWAN, and other LNS platforms.

Planned Specifications

LoRaWAN

Specification	LoRaWAN 1.0.3
Class	A & C
Activation	OTAA, ABP
Range	10+ km (rural), 2-5 km (urban)

Modbus Interface

Protocol	Modbus RTU (RS-485)
Baud Rate	1200 - 115200 bps
Configuration	Via network server

Network

Regions	IN, EU, US, AU, AS
Platforms	ChirpStack, TTN, AWS
ADR	Adaptive Data Rate

Power & Physical

Input Voltage	12-24V DC
Operating Temp	-20°C to +70°C
Mounting	DIN rail 35mm

Ideal For

🏙️

Smart Cities

City-wide sensor networks for parking, lighting, environmental monitoring, and waste management.

🌾

Agriculture

Distributed soil sensors, weather stations, and irrigation control across large agricultural areas.

⚡

Utility Networks

Smart metering, grid monitoring, and distributed asset management for utilities.

🏭

Industrial Campuses

Large facility monitoring with centralized network management and multiple gateway infrastructure.
